DIN 933 // ISO 4017BIS Certified (IS 1364)
ISO 9001:2015Quality Audit
RoHS / REACHHeavy Metal Free
NABL LABTraceable Mill
DIRECT FACTORY OEM FASTENERS • RAW METRIC HARDWARE
DIN 933 Hexagon Head Full Thread Set Screws (M10 × 110mm)
Thread Diameter (d):M10
Nominal Length (l):110 mm
Property Class / Grade:5.8 Blkzp
Surface Finish / Coating:Black Zinc Phosphated (Blkzp)
₹ 9.14/ Piece
Excluding 18% GST • Net Weight: ~63.1g per piece| Volume Batch | Discount Slab | Effective Price |
|---|---|---|
| 100 – 999 PCS | Base Rate | ₹ 9.14 / Pc |
| 1,000 – 4,999 PCS | 10% OFF | ₹ 8.23 / Pc |
| 5,000 – 19,999 PCS | 20% OFF (Contractor) | ₹ 7.31 / Pc |
| 20,000+ PCS | 26% OFF (OEM Master) | ₹ 6.76 / Pc |
Quick Quantities:
Pan-India Heavy Logistics Carrier Dispatch
Same-day dispatch for orders confirmed before 3:00 PM IST from Mumbai Central Logistics Hub.
✓ Delivery in 24-48 Hours to Mumbai Metropolitan Region100% Quality & Thread-Gauge Guarantee
Every lot is physically calibrated with calibrated go/no-go ring gauges before packing. Free 30-day return on metallurgical variance.
| Manufacturing Standard | DIN 933 / ISO 4017 / IS 1364 (Part 2) |
|---|---|
| Thread Pitch (P) | 1.50 mm (Metric Coarse Standard ISO 965-2) |
| Head Height (k) | 6.40 mm (Tolerance js14) |
| Width Across Flats (s) | 17.00 mm (Standard Hex Socket Wrench Size) |
| Width Across Corners (e) | 18.90 mm minimum |
| Tensile Strength (Rm) | 500 N/mm² minimum (Class 5.8) / 800 N/mm² (Class 8.8) |
| Proof Stress (Sp) | 400 N/mm² (Yield Ratio 80%) |
| Elongation at Break (A5) | 12% minimum |
Frequently Procured Assembly Kit (Screw + Nut + Washer)
DIN 934
Hexagon Full Nuts Grade 8 (M10)₹ 1.84 / Pc
DIN 125A
Form A Flat Plain Washers (M10)₹ 0.72 / Pc
DIN 127B
Split Spring Lock Washers (M10)₹ 0.95 / Pc
